Dodge Journey Wheel Bolt Pattern, Rim Size, Hub Bore, Offsets, and Tire Size

Introduction

From the family-friendly JC49 (2008–2020) to the globally influenced 2021–2026 model, the Dodge Journey has witnessed notable change over its manufacturing run. Though Journey owners sometimes neglect it, wheel fitment is rather important for the safety, riding comfort, and appearance of the car. Changing the correct tires and wheels guarantees not only safe and smooth driving but also improves the whole stance and performance of your Journey. While offering useful advice on aftermarket improvements, measurements, and where to shop, this guide will dissect all the important wheel fitment standards for both generations.

Whether you have an older JC49 or the newest generation Journey, knowing the variations in fitment can help you choose new wheels and tires. Let's go right into the details.

Understanding Wheel Fitment

Wheel fitment requires multiple exact measures that guarantee your wheels fit safely and perform correctly, not only in the choice of wheel size. The main components consist of:

• Bolt Pattern: Number of lug holes and their spacing.


• Rim Size: The diameter and width of the wheel.


• Hub Bore: The center hole that aligns the wheel on the hub.


• Offset: How far the wheel sits in or out from the hub mounting surface.


• Tire Size: The tire’s width, aspect ratio, and rim diameter..


Handing, braking, tire wear, and look all depend on the right mix. Misfit wheels can create vibration, rubbing, or worse—unsafe driving circumstances.

Dodge Hornet Wheel Bolt Pattern, Rim Size, Hub Bore, Offsets, and Tire Size

Dodge Journey JC49 (2008–2020) Wheel Fitment Guide

Over all years and cuts, the JC49 Journey boasts a 5x127mm (5x5") bolt pattern. Common among mid-sized SUVs, this pattern offers a strong mounting surface for OEM and aftermarket wheels. Depending on the trim level, factory-installed rims on the JC49 span 17 inches to 19 inches. Popular additions are 20-inch wheels for individuals looking for a more aggressive, filled-out look without sacrificing comfort. Using OEM-style wheels lets the factory hub bore— 71.5mm—allow direct fitting on the hub without requiring hub-centric rings. The Journey JC49 guarantees the wheels sit flush without scratching or prodding the fenders by using an offset range between +35mm and +42mm. Depending on the trim and rim size, original tire sizes fall from 225/65R17 to 225/55R19. Custom applications often call for 255/50R20 when switching to 20-inch wheels, blending comfort and sportiness.

Dodge Journey (2021–2026) Wheel Fitment Guide

Reflecting their same base as the GAC GS5, the current generation Journey has a 5x108 mm bolt pattern. JC49 wheels are, therefore, incompatible with this adjustment. The factory rim diameters run from 17 to 19 inches; higher trims usually include the larger size. For a more elegant appearance, aficionados sometimes replace their rims with 220-inch rims with a hub bore of 60.1mm, much smaller than in past generations. Exact fitting is needed for appropriate wheel centering. Keeping the wheels nicely tucked inside the fenders, factory offset on the next generation Journey falls between +40mm and +45mm. Comprising 225/65R17 and 235/55R19, standard tire sizes provide a decent blend of comfort and fuel economy. Correct offset and no fender changes allow one to upgrade to 245/50R20 as well.

Key Differences in Wheel Fitment Between JC49 (2008–2020) and 2021–2026 Journey

The most obvious change is from a 5x127mm to a 5x108mm bolt pattern, therefore rendering wheels non-interchangeable between the two versions. The hub bore dropped from 71.6mm to 60.1mm as well as the offset range became more conservative in the more recent models. These developments mean the younger Journey prefers wheels made for small SUVs, while the JC49 may manage somewhat wider, more aggressive configurations.

Can You Use JC49 Wheels on the New Generation Journey?

No, there is no compatibility between the generations for the wheels. Direct swap is dangerous and unworkable due to variations in bolt design, hub bore, and offset. Safety concerns and handling problems make it even with adapters not advised. Always follow wheels made especially for your model year of Journey.

Popular Aftermarket Wheels and Tires for Dodge Journey

Rugged and sporty designs abound for JC49 owners from firms such Fuel Off-Road, American Racing, and Moto Metal. With its sleek and small form, the younger generation Journey appeals modern, urbanly and fits brands like Motegi Racing, OHM, and TSW. For touring, Michelin, Goodyear, and Falken offer excellent choices; among performance seekers, Nitto and Toyo are favorites.

How to Measure Bolt Pattern, Offset, and Hub Bore for Dodge Journey

Measure from the middle of one lug to the furthest opposite lug to ascertain the bolt pattern. Use a digital caliper for exact center hole measurement for hub bore. A bit more difficult, offset usually necessitates removing the wheel and gauging the distance from the hub mounting surface to the centerline of the wheel. Consult a wheel fitment specialist or utilize an online fitment calculator if you are a novice, to be sure.
