Acura Integra Wheel Bolt Pattern, Rim Size, Hub Bore And Offsets
Introduction
From its 1986 introduction, the Acura Integra has been a shining example of performance and design. Celebrated for its athletic look and speed, the Integra has changed over multiple generations, each adding distinctive features and tweaks. Maintaining the handling qualities and cosmetic worth of the vehicle depends on knowing the right wheel fitment. We will discuss in this guide the particular needs for hub bore, bolt pattern, tire size, rim size, and offset that every generation brings. Let's explore the exact requirements to guarantee you find the ideal fit for your journey.
Understanding Wheel Fitment
Choosing the correct wheels for your Acura Integra requires knowledge of many important factors, including bolt pattern, hub bore, offset, tire size, and rim width. These elements guarantee not only fit but also improve the performance and appearance of the car. Proper installation depends on the bolt pattern matching. While the offset should be sufficient to prevent the tires from rubbing against the fender or suspension components, the hub bore should be exactly aligned to eliminate vibrations. Choosing the right tire and rim size influences the speedometer and odometer readings as well as adds to the overall beauty of the vehicle. Any one of these areas can suffer from mistakes that might cause poor performance, more tire wear, or even car damage.
Basics of Wheel Fitment
Though it varies along the range from 4x100 mm to 5x114.3 mm in later versions, the Acura Integra's bolt pattern usually stays constant within each generation. Usually starting around 56.1 mm, the hub bore grows in scale in more recent versions to fit contemporary hub designs. Achieving the intended vehicle profile without sacrificing the functioning depends on knowing the offset, which ranges from +35 to +50 mm depending on the generation and desired stance.
Common Fitment Issues
Potential for wrong offset or bolt patterns, which causes alignment issues or uneven tire wear, is one of the most frequent problems when switching from stock to aftermarket wheels. Another problem would be selecting a rim size too big, which would call for bodywork changes to stop rubbing of the vehicle. Following the suggested tire size and offset guidelines helps you reduce these dangers.
First Generation (1986–1989) Acura Integra Wheel Fitment
With their athletic attributes and nimble configuration ideal for modifications, the Acura Integra's first generation set the tone. Though modest, stock wheels were appropriate for their time; aftermarket options allow for improvement.
Factory Wheel Specs
The first models perfectly balanced the small size of the car with its 4x100 mm bolt pattern, 14x5.5 inch rims, and +45 to +50 mm offset. Standard for many little cars of the time, the hub bore was 56.1 mm, guaranteeing a smooth ride free from adjustments.
Best Aftermarket Fitment Options
Stepping up to 15x6.5 or 15x7 inch rims can help individuals wanting to improve their first-generation Integra take a more aggressive posture without sacrificing the traditional appearance. Choosing a +35 to +40 mm offset lets one have a somewhat wider stance, therefore enhancing grip and handling. This upgrade's suggested tire size, 195/50R15, preserves speed accuracy and provides better road sensation.
Second Generation (1990–1993) Acura Integra Wheel Fitment
The Integra evolved in wheel fitment choices as well. More solid changes were possible since this generation started to tilt more toward performance.
Factory Wheel Specs
While the GS versions were improved to 15 inches, preserving the 4x100 mm Bolt pattern and a little offset range of +38 to +45 mm, Standard models continued with 14x5.5-inch rims. The constant 56.1 mm hub bore size helped to smoothly move to bigger aftermarket choices.
Best Aftermarket Fitment Options
Fans wanting to customize their second-generation Integra usually choose 15x7 or 16x7 inch rims. 16x8-inch rims can be fitted with minor tweaks such as fender rolling for those wanting a more aggressive look and performance. 205/45R16 would be the perfect tire size for these rims since it provides a balanced appearance and improved road handling without appreciable car dynamics.
Third Generation (1994–2001) Acura Integra Wheel Fitment
This period saw the Integra, particularly with the Type R's arrival, attain its peak performance capacity. Customizing choices grew more varied to suit an increasing vehicle enthusiast population.
Factory Wheel Specs
While the GS-R and Type R versions had 15x6 inches, this generation presented a range from 14 to 15 inches in rim diameter. While the ordinary models stayed to 4x100 mm, the Type R had a 5x114.3 mm bolt pattern with a bigger hub bore of 64.1 mm. Designed for performance and clearance, the offsets ran from +45 to +50 mm.
Best Aftermarket Fitment Options
Standard models would want 15x7 or 16x7 inch rims to preserve their agile character. Often upgrading to 16x7 or 17x7.5 inch rims, Type R owners put 215/45R17 tires for better handling and a sportier appearance. Those who want a lower, more aggressive posture should look at 17x8.5-inch rims with a reduced offset and fender adjustments.
Fourth Generation (2002–2006) Acura Integra RSX Wheel Fitment
Known in some regions as the RSX, this version represented a major change in style and performance, appealing to a modern audience with its polished looks and improved capability.
Factory Wheel Specs
Both using a 5x114.3 mm bolt pattern, the Type-S sported 17x7-inch rims while the original model had 16x6.5 inch rims. The offsets were kept between +45 and +55 mm, giving enough room and a strong stance. Complementing contemporary Acura models, the hub bore stayed at 64.1 mm.
Best Aftermarket Fitment Options
Those modifying their RSX usually choose 17x8 or 18x8.5 inch rims for a balanced boost above stock capabilities. More ambitious changes may be 18x9.5 inch rims, which call for precise offset and possible body modification to avoid friction. While providing a new, aggressive style, tire selections like 225/40R18 assist preserve the car's original handling characteristics.
Fifth Generation (2022–Present) Acura Integra Wheel Fitment
Incorporating cutting-edge technology and a sleek style to appeal to current consumers, the newest generation of the Integra re-introduces the nameplate with a modern spin.
Factory Wheel Specs
Standard rims for the new versions are more substantial; 17x7.5 inches on the A-Spec and an aspirational 19x9.5 inches on the Type S. Reflecting its modern engineering and performance emphasis, the bolt pattern has moved to a more durable 5x114.3 mm with a +50 mm offset and a 64.1 mm hub bore.
Best Aftermarket Fitment Options
18x8.5-inch or 19x9-inch rims improve a daily driver without compromising the car's utility or comfort. With tires sized 235/40R19 or 265/30R20, the Type S may comfortably fit 19x9.5 or even 20x9.5 inch rims, hence improving its stance and road presence. These modifications improve the road-handling capacity of the vehicle as well as its outward look.
Bonus Section: Lug Nut Torque Specs by Generation
Properly torqued lug nuts are crucial for safety and performance. Here’s a quick rundown for each generation:
-
First Generation: 80 lb-ft
-
Second Generation: 80 lb-ft
-
Third Generation: 80 lb-ft
-
Fourth Generation (RSX): 80 lb-ft
-
Fifth Generation: 90 lb-ft
Conclusion
The appearance and driving pleasure of your Acura Integra will be much enhanced by the choice of wheels. Whether you drive a vintage first-generation or the newest model, knowing the details of wheel installation helps guarantee that your additions improve the performance and appearance of your automobile. When selecting your new set of wheels, always take into account elements including brake clearance and your normal driving circumstances. Visit HulkOffsets.com for the finest options and professional guidance.
