Acura TLX Wheel Bolt Pattern, Rim Size, Hub Bore And Offsets

Introduction

Since its 2015 launch, enthusiasts and luxury sedan aficionados have come to love the Acura TLX. Whether you're looking for a daily cruiser or a sleeper build, it's a flexible choice since it lies naturally between performance and comfort. Whether your TLX is the first-generation vehicle or the more recent second-generation, though, knowing appropriate wheel fitment is vital to maximize it. Selecting the right wheel specs is about guaranteeing that handling, safety, and ride quality are all tuned in, not only appearance.

Designed for anyone wishing to replace or modify their TLX wheels, this guide will walk you through all from manufacturer specs to popular aftermarket advice. We will discuss both generations of the TLX, go closely into bolt patterns, offsets, hub bores, tire widths, and even some aftermarket fitment advice.

Understanding Wheel Fitment Basics

Understanding a few basic wheel terminologies you will often come across is crucial before diving into TLX-specific fitments. First, your wheels bolt onto the car using a wheel bolt pattern. Usually written as "5x114.3," it means five lug nuts with a 114.3mm circle diameter. Get this mistaken, and the wheels won't mount at all.

The rim size comes next; usually expressed as diameter x breadth, say 18x8.0. While width shapes the tire's footprint and stance, diameter determines appearance and tire sidewall height. Depending on trim and generation, most factory TLX wheels run from 17 Inch to 20 Inch.

The hub bore—the center hole of the wheel—fits onto the hub of your car. Usually with a 64.1mm hub bore, aftermarket wheels should match or employ hub-centric rings for a close fit.

One of the easiest but most crucial elements is offset. It tells how far in or out your wheel rests in the fender and is expressed in millimeters. Lower offset drives the wheel outward; positive offset pulls it inward. Depending on the year and trim, the TLX runs offsets between +40mm and +55mm.

Finally, consider tire size; this is all about balancing sidewall height, width, and diameter to preserve correct speedometer calibration and prevent rubbing problems. Generation influences the variation in OEM tires between 225/50R17 and 255/35R20.

Acura TLX 1st Generation Wheel Fitment (2015 - 2020)

Made between 2015 and 2020, the first-generation Acura TLX came in two primary models: the 3.5L V6 and the 2.4L Inline-4. Though each came with somewhat different wheel and tire combinations, both provided a mix between sporty handling and luxury comfort.

The factory wheel bolt pattern for the 2.4L FWD versions is 5x114.3mm and the hub bore is 64.1mm. Stock wheel sizes fall between 17x7.5 and 18x7.5; offsets usually run between +45mm and +55mm. These configurations were tailored more toward efficiency and comfort.

Especially those with Super Handling All-Wheel Drive (SH-AWD), the 3.5L V6 cars came with somewhat wider and bigger wheels. On A-Spec cuts, factory sizes run from 18x7.5 up to 19x8. Depending on trim, the offset stays between 50mm and 55mm. When aiming for a flush of the wheels with the fenders, SH-AWD versions typically gain from somewhat smaller offsets.

Usually ranging from 225/50R17 to 245/40R19, tire sizes for the first generation Often running the larger 245/40R19 setup are SH-AWD vehicles. For a more aggressive yet functional fitment, enthusiasts aiming for an OEM+ look generally choose 19x8.5 wheels with a +40mm offset combined with 255/40R19 tires.

Clearance for pushing for larger wheels presents the biggest difficulty with this generation. Consider anything larger than 8.5" with low offsets carefully, as you may run across rubbing without modest fender work or suspension adjustments.

Bolt Pattern, Offset, Center Bore & Lug Specs (200 words)

• Bolt Pattern: 5x114.3



• Center Bore: 64.1mm



• Offset Range: +45mm to +55mm (OEM), +35mm to +54mm (aftermarket flush)



• Lug Nut Thread Pitch: M12x1.5



• Recommended Lug Torque: 80-90 lb-ft

Because their bolt pattern and hub bore are the identical, 2.4L and 3.5L models allow aftermarket wheels to be swapped across trimers. But the offset varies somewhat; the V6 and SH-AWD trims prefer larger offsets because of their suspension architecture. Wheel security depends on Lug torque, hence always torque to spec.

Read About: Integra Type-S Wheel Fitment

Acura TLX 2nd Generation Wheel Fitment (2021 - Present)

Arriving in 2021, the second-generation TLX improved Acura's midsize sedan performance. Its more aggressive posture and longer, wider stance on a new platform inevitably influence wheel fitting.

The 5x 120mm bolt pattern and 64.1mm hub bore of Standard TLX models (2.0L Turbo) are retained From 18x8.5 on base models to 19x8.5 on A-Spec trims, factory wheel sizes range. Usually, factory offsets span +29mm to +55mm.

Introduced as the performance flagship, the TLX Type S steps it with 20x9.0 wheels from the manufacturer combined with 255/35R20 tires. Though many owners who prefer a more aggressive posture drop to +40mm to +45mm offsets when pursuing aftermarket, the offset is roughly +52mm. The Type S also has bigger Brembo brakes, hence choose wheels carefully to prevent clearance problems with regard to spoke design.

Especially if you lower the car somewhat, one benefit of the 2nd-generation TLX is that you can safely run 19x9.5 or even 20x9.5 wheels with the appropriate offset (+40mm to +45mm) without notable rubbing. Just keep in mind to blend drivability with appearance.

Depending on trim, tire sizes for the second-generation range from 235/40R19 to 255/35R20. Most owners upgrading on aftermarket configurations for enhanced traction using 265/35R20 tires choose not to compromise ride comfort.

Bolt Pattern, Offset, Center Bore & Lug Specs

• Bolt Pattern: 5x120mm



• Center Bore: 64.1mm



• Offset Range: +50mm to +55mm (OEM), +29mm to +55mm (aftermarket)



• Lug Nut Thread Pitch: M14x1.5



• Recommended Lug Torque: 80-90 lb-ft

All second-generation TLX vehicles share these parameters, although Type S trims should be especially careful due to Brembo brake clearance. Many aftermarket products list "Type S fitment" as indicating fit.

Wheel Size Comparison (2015-2025 TLX Models)

Here's a helpful comparison of TLX wheel specs across the years:

This table allows you a fast review of the TLX's wheel sizing evolution. For a sportier appearance and feel, see how the second-generation TLX shifted toward larger wheels and lower-profile tires.

Fitment Tips & Considerations

Beyond simply bolt pattern and offset, there are several factors to consider when mounting aftermarket wheels on a TLX. First, particularly on TLX Type S versions with Brembo brakes, always be careful of brake clearance. Though many wheels will theoretically "fit," they could have caliper clearance problems.

Combine broad wheels with low offsets carefully, whether utilizing springs, coilovers, or air suspension, to reduce their TLX. With offsets in the +35mm to +45mm range, most configurations find a decent sweet spot in 19x9.5 or 20x9.5. Especially when combined with a modest drop, this usually results in a flush look devoid of rubbing.

Tire size is also really crucial. Under full lock or severe cornering especially, going too wide might cause friction or poor handling. Aggressive fitment on 1st-generation TLX finds success in 255/40R19 or 255/35R20. Using the proper offset, you can push 265/35R20 on the second-generation.

Running aftermarket wheels should always be done using hub-centric rings as another important piece of advice. Given the TLX hub bore of 64.1mm, be sure the wheels either match or utilize rings to prevent vibrations.

Finally, don't forget alignment once new wheels or lowered cars are installed. Maintaining your alignment helps to ensure the car drives straight and safely as well as to extend tire life.

Top Recommended Wheels for Acura TLX

With the correct wheel set, the TLX—first or second-generation—looks amazing. Among TLX aficionados, Spec-1, TSW, Azara, Asanti, and Niche are some of the most often used brands. Strong, elegant, well-engineered wheels that hold up to regular driving while enhancing the appearance of your TLX are well-known from these companies.

Typically using a +40mm to +45mm offset, enthusiasts choose 19x8.5 or 19x9.5 for a pristine OEM+ look. Particularly on the second-generation TLX Type S, 20x9.5 wheels with offsets in the +35mm to +42mm range are typical if you're pursuing a sportier or more aggressive stance.

Lightweight flow-formed wheels from companies like Enkei or Konig will cut unsprung weight and enhance handling if you enjoy a performance-oriented build. Conversely, if you lean more toward show or stance, the TLX has a more forceful presence from deep concave wheels with a reduced offset.

Whichever your style, always give quality first priority over appearance alone. Especially if you drive aggressively or have changed suspension, avoid budget wheels without appropriate load ratings.

Shop Acura TLX Wheels at HulkOffsets

HulkOffsets provides the ideal set of wheels just for your Acura TLX right here. Including the high-performance Type S models, HulkOffsets provides a large range of wheels suitable for both the first and second generations TLX as a committed wheel expert.

HulkOffsets distinguishes itself by stressing confirmed fitments. HulkOffers wheels guaranteed to fit, so you save yourself guessing offsets, bore diameters, or whether the wheels will clear your Brembo brakes. From aggressive stance and performance wheels to subdued OEM+ models, you will find choices exactly matching your idea.

Hulk offers both a full-blown 20x10.5 exhibition build and a 19x9.5 arrangement for a daily driver. They also carry well-known, reliable brands such as Vossen, XF Off-Road, Cavallo, and Spec-1 Wheels. Need guidance in decision-making. Based on your goals and budget, their staff can even help you with personal recommendations.

Visit www.hulkoffsets.com to investigate TLX-specific solutions. Along with fitment advice, tires, and accessories meant to ensure you drive safely and more smoothly, you will also find tools to help you drive away not only looking better.

Final Thoughts

Whether your model is a brand-new Type S or an early 2015 model, the Acura TLX is a platform yearning for elegant wheel changes. Understanding fitting basics— Bolt pattern, offset, center bore, and tire size—you make sure your upgrade improves looks and performance without causing issues like friction, bad handling, or wheel vibration.

Wheel fitting is not only about numbers on paper, though. It's about daily handling, steering, and sitting of your car. In addition to making your TLX unique, a well sized and well-selected wheel set will provide road peace of mind. Invest a bit more time or money to find the fitment.

And fit, don't hesitate to contact wheel experts like the people at HulkOffsets if you still feel uncertain or overwhelmed. They can help you acquire exactly what you need and interact with Acura TLX owners daily.

You now fully see the picture. Go ahead and claim your TLX.
