Chrysler 200 Wheel Bolt Pattern, Rim Size, Hub Bore And Offsets

Introduction

Introduced as a midsize sedan with a pleasant ride, reasonable performance, and stylish appearance, the Chrysler 200 Designed and engineered with great alterations across two generations, this model was produced between 2011 and 2017. Understanding a Chrysler 200's wheel fitment is absolutely vital for both owning and customizing it. Selecting the right wheel size guarantees a safe and comfortable driving environment in addition to improving the appearance of your vehicle.

Several elements influence proper wheel fit: bolt pattern, offset, rim size, hub bore, and tire specifications. Every generation of the Chrysler 200 has unique features, thus installing the wrong wheels could result in poor handling, more wear on suspension parts, or even safety concerns. This article will walk you through all you need to know whether your preference is OEM specs or an aftermarket update.

We will discuss fitting specifics for both generations and provide advice on wheel choice to fit your needs. This guide is meant to assist you make wise decisions from stock sizes to custom options. Let's begin by considering the particular wheel needs of the first-generation Chrysler 200.

Read About: Chrysler Voyager Wheel Fitment

Understanding Wheel Fitment Terminology

Navigating wheel upgrades requires knowledge of some fundamental yet necessary vocabulary. Allow me to dissect it here.

• Bolt Pattern is the diameter of the circle formed by the lug holes. Five lugs spread across a 114.3mm diameter circle, for instance, is 5x114.3. It has to completely match your car to correctly mount the wheel.

• Rim Size is wheel diameter expressed in inches. It must match the right tire size to maintain your total wheel diameter within the manufacturer spec for drivability and safety.

• The offset is the distance from the mounting hub of the wheel to its centerline. Negative offset pushes the wheel outward; positive offset—common in FWD cars—means the hub is closer to the outside. Avoidance of clearance problems depends on staying inside the advised offset range.

• Hub Bore: On your car, the central hole of the wheel—hub bore—fits over the hub. Perfect fit guarantees driving free of vibration. If your wheels have a bigger bore, use hub-centric rings.

• Tire Size: Combining width, sidewall height, and rim diameter (e.g., 235/45R18), tire size is Every component affects speedometer accuracy, riding comfort, handling. Always select tires that as closely as possible preserve the standard rolling diameter.

First Generation Chrysler 200 (2011–2014)

Overview of First Generation

The first model of the Chrysler 200 was essentially a rebadged, considerably upgraded variation of the Chrysler Sebring. It got a fresh design, better inside, and revised powertrains but kept the same general basis. Approved in both sedan and convertible body forms, it attracted drivers looking for a reasonably priced yet sophisticated midsize car.

Its two major engine choices under the hood were a more durable 3.6L V6 and a 2.4L inline-four. Although its mechanical bones were not much different from its predecessor, the appearance and comfort enhancements made it more appealing. By bridging the difference between Chrysler's older designs and the more modern second generation, this generation set the groundwork for what the 200 would become.

Though sometimes disregarded in the aftermarket scene, the first-generation 200 has lots of possibilities for customizing, particularly in the wheel area. Knowing the right specs is the first step; a decent pair of wheels will greatly affect the appearance and posture of the car.

Wheel Specifications

Standard wheel bolt pattern for the 2011 to 2014 Chrysler 200 is 5x114.3mm. The trim determines whether the stock rim diameters fall between 17 and 18 inches. While higher trims or versions using the V6 engine could get 18-inch alloys, base models often came with 17-inch wheels.

Unless hub-centric rings are used, the hub bore—67.1mm—is crucial to match when choosing aftermarket wheels. Usually falling between 40 and 44mm, the offset places the wheels precisely within the fenders and helps to avoid clearance problems.

Regarding tire sizes, standard trims usually call for 215/55R17; upgraded models could have 225/50R18. These tires provide a harmony of road grip and ride comfort. Many owners pick somewhat wider or lower-profile tires for a sportier appearance when switching to aftermarket options, but it's important to maintain the rolling diameter within 3% of the factory size to prevent speedometer errors and rubbing problems.

Knowing these manufacturing parameters gives you a strong basis if you are thinking about an update and helps you keep safety and performance.

Aftermarket Wheel Options

Regarding personalizing your first-generation Chrysler 200, the wheel choices create a lot of performance and esthetic possibilities. Its ubiquitous 5x114.3 bolt design allows a large selection of aftermarket wheels from which to draw. Many well-known brands have designs that fit without calling for too dramatic changes.

Though you can go up to 19 or even 20 inches in diameter, keep aware of the offset and breadth to prevent rubbing or suspension interference. Typically with a width between 7.5 and 8.5 inches, ideal aftermarket configurations have an offset range of 38mm to 45mm. This maintains the aggressive but pragmatic posture.

Although a staggered arrangement isn't often employed on this platform, with the correct planning you can achieve a more performance-oriented design. While deep dish or concave forms create a strong look, lightweight metals are an excellent option to save unsprung weight and increase responsiveness. Just be sure you constantly test fit whenever you can and match your new wheels with suitable tire sizes.

The aftermarket scene has lots to offer first-generation Chrysler 200 owners whether your taste is for flamboyant and athletic or elegant and subdued.

Second Generation Chrysler 200 (2015–2017)

Overview of Second Generation

Introduced in 2015, the second generation Chrysler 200 broke completely from its predecessor. Built on Compact US Wide (CUSW) platform of Fiat Chrysler, it shared parts with Dodge Dart and Jeep Cherokee. Both inside and outside, this generation displayed a far more modern design and gave comfort, safety, and driving dynamics top priority.

It turned away the convertible choice and arrived just as a four-door sedan. It gave both efficiency and punch with engine choices including the 2.4L Tigershark and the potent 3.6L Pentastar V6. Complementing a 9-speed automatic transmission, the second-generation 200 was designed for flawless shifting and polished highway driving. On V6 vehicles, all-wheel drive offered traction and adaptability as well.

Its higher luxury wheel choices also represented the design improvement. The fitment standards changed somewhat, therefore you cannot interchange wheels across generations without first ensuring compatibility. Those seeking quality features without a luxury designation turned to this generation first.

Wheel Specifications

Unlike the original generation, the 2015–2017 Chrysler 200 vehicles employ a 5x110mm bolt pattern. From 17 inches to 19 inches, factory wheel sizes range; 17-inch wheels being found on cheaper trims and 18 or 19-inch alloys on sportier or more luxury models.

This generation's hub bore is 65.1mm; thus, it's crucial to match exactly or utilize hub-centric rings to stop vibration. Usually falling between 40 and 45mm, the offset range is perfect for preserving correct alignment and clearance.

Common tire sizes are 215/55R17, 235/45R18, and 235/40R19. Every size provides a decent mix between handling and ride quality; the larger wheels give a livelier, more aggressive posture. Choose aftermarket wheels such that the replacement tires don't travel too far from the original diameter to prevent speedometer and other sensor calibration problems.

The wheel specs of this generation fit a more refined and current look, so if you intend an upgrade, the correct wheels will improve the performance and appearance of the automobile.

Aftermarket Wheel Options

Changing the wheels on your second-generation Chrysler 200 will improve both road feel and looks. Your choice is somewhat more constrained than on the previous generation due to the less common 5x110mm bolt design, but there are still several credible brands that match this fitment.

Often seeking 18 or 19-inch aftermarket wheels to accentuate the sporty, luxury appearance of this generation, owners Usually, the arrangement calls for an offset between 38mm and 45mm together with a width between 8 and 8.5 inches. This guarantees a good fit without call for spacers or adjustments.

Tighter wheel wells on this model mean that tire dimensions must be kept near to stock. While widening could give your motorcycle an aggressive appearance, be careful not to rub over hills or during turns. While flow-formed wheels give strength without the great cost, lightweight built wheels are a great choice for lowering rotational mass.

See directional spoke designs or custom powder-coated finishes for individuals seeking a distinctive look. Just keep in mind that appropriate fitting research should support every improvement to maintain safety and performance.

Factors to Consider When Choosing Wheels

Selecting the correct wheels transcends appearance. Wheel choice can affect performance, comfort, durability, even fuel economy. Decide first whether your main objectives are for improved off-the-line speed, better handling, or visual appeal. Although they can lower riding comfort, larger wheels usually look prettier and offer greater cornering.

Think through wheel materials as well. While built wheels are stronger and lighter but cost much more, cast wheels are reasonably priced and commonly available. A superb compromise between weight and strength, flow-formed wheels provide

Check that the bolt pattern, hub bore, and offset of your new wheels match those of your car. Using wheels with the incorrect offset will strain your suspension or lead to friction. In the same vein, unless you utilize centering rings, a misaligned hub bore might cause vibrations. Remember also the impact on tire wear and fuel economy.

At last consider your own climate. Having a separate set of winter wheels and tires is wise in places with severe winters. Though they look fantastic, powder-coated or painted wheels need extra care to withstand road salt deterioration. Match your wheels always to your environment and manner of living.

Installation Tips

Once you have chosen your wheels, appropriate installation is rather important. Check first that the bolt pattern, rim size, offset, and hub bore all fit your car's specs. Use hub-centric rings to remove vibrations if the hub bore of your wheels is off exactly.

Clear the hub surface before installation to make sure there is no corrosion or trash that can keep the wheel from seated correctly. Following manufacturer torque specs, usually around 100 lb-ft for the Chrysler 200, tighten the lug nuts in a star pattern using a torque wrench. Uneven torque or over-tightening might cause warped brake rotors or wheel stud damage.

Turn the wheel totally side-to--side and check clearance in the wheel well if you use aftermarket wheels with varying offsets or widths. Testing drive and listening for any vibrations or sounds is a smart approach.

Eventually, every 50 to 100 miles of driving, always re-torque your lug nuts. This guarantees right settling of everything. Good installation techniques help to preserve the lifetime of your wheels and suspension parts as well as to ensure safety.

Maintenance and Care for Your Wheels

From potholes and brake dust to extreme weather, wheels bear a lot. Maintaining their look and use depends on their being taken care of. Starting with a pH-balanced wheel cleanser and a soft brush, routinely clean your wheels. Steer clear of acidic cleaners that can discolor or damage finishes.

Look for unequal wear on your tires to suggest either misalignment or suspension problems. To encourage even tread life, rotate your tires every five,000 to seven,000 miles. If you reside somewhere with winter, think about covering your wheels with ceramic coating for extra defense against road salt.

Periodically, check for cracks, bending, or corrosion—especially if you come over a pothole. In addition to ruining the ride, damaged wheels seriously compromise safety. See a professional to have your wheels balanced and aligned if you detect high speed vibration.

Remember also your tire pressure at last. Keep it inside the suggested PSI indicated on your door frame. While overinflated tires lower traction, underinflated tires wear out faster and compromise fuel economy. Your wheels will keep looking sharp and functioning for years with regular care.

Conclusion

Choosing the correct wheels for your Chrysler 200 calls for more than just aesthetic taste. From aftermarket possibilities to manufacturing criteria, the first and second generations have different fitment needs. Your automobile rides and feels quite differently depending on your bolt pattern, rim size, hub bore, offset, and tire size.

Matching the requirements guarantees safety, performance, and peace of mind whether your project calls for a dramatic upgrade or you are maintaining current stock. With their 5x 114.3 design, the first generation allows you freedom; the second generation offers a polished, elegant platform with a 5x 110 bolt pattern.

Refer to this information anytime you are looking for tires or wheels. The appropriate configuration will improve the appearance, handling, and even resale value of your Chrysler 200. Remember: every detail matters and, armed with the right information, you will roll down any road with assurance.
