Dodge Dart Wheel Bolt Pattern, Rim Size, Hub Bore, Offsets, and Tire Size

Introduction

Over automotive history, the Dodge Dart has had an interesting trip. From its iconic small-muscle beginnings in the 1960s to its contemporary revival in the 2010s, the Dart has always carried its character. Whether your car is a classic Dart or a more recent PF generation model, knowing its particular wheel fitment is vital. It's not only about appearances; correct wheel measurements guarantee handling, safety, and prevent expensive errors, including rubbing or early tire wear.

The precise wheel specs of every generation—including bolt pattern, rim size, hub bore, offset, and tire size—are walked over using this guide. Whether your Dart is kept in stock or you want to go all-out with bespoke modifications, we will also discuss best practices when choosing new wheels and tires. Let's dissect every era so that you may clearly see what suits and improves the driving experience of your Dart.

Understanding Wheel Fitment

Though it sounds scientific, wheel fitment is easier when you dissect it. Important for matching your Dart's wheel hub, the bolt pattern is the arrangement of lug holes on the wheel hub. Tire choice and handling depend on rim size, which covers width as well as radius. Critical for alignment and balance, the hub bore is the hole in the middle of the wheel that fits over the hub. Affects stance and clearance, offsetting the distance the mounting surface of the wheel runs from its centerline. Tire size affects the width and height of the tire, so it impacts comfort and grip.

Ignorance of these could lead to rubbing, handling instability, or even brake interference. Before purchasing aftermarket wheels or tires, always confirm these measurements. For novices, tools such as offset calculators and bolt design templates can be quite helpful. This basis guarantees the wheels you choose will not only look fantastic but also fit like a glove and run safely.

Dodge Caliber Wheel Bolt Pattern, Rim Size, Hub Bore, Offsets, and Tire Size

Dodge Dart III (1963–1966) Wheel Fitment Specifications

Produced between 1963 and 1966, the Dodge Dart III was a little automobile that had a big influence on the muscle car scene. With a 5x4.0" (5x101.6mm) bolt pattern and a modest but era-appropriate arrangement for little muscular needs, this model is, though by today's standards small, factory rim diameters ranging from 13x5.0 inches, which were common for the time. With a 59.2mm hub bore and usually around 0mm factory offsets, these vehicles have a neutral stance. Standard tire sizes in modern terms were roughly 185/75R13, or 7.00–13 bias-ply tires.

Owners may choose 14" or even 15" rims for a little enhancement in handling and look when changing wheels. Wider wheels should be used carefully, though, since without fender modifications, the short wheel wells can restrict tire width. Selecting the appropriate offset becomes vital to keep the tire tucked inside the fenders without rubbing on suspension parts.

Recommended Wheels and Tires

Popular improvements for owners rebuilding or personalizing a Dart III are 15x6 or 15x7 inch wheels with a 0 to 6mm offset. Wheel wells are nicely filled out by tires like 205/60R15 or 215/60R15 without generating clearance problems. Using adapters to a 5x4.5" (5x114.3 mm) pattern or closely following the original Bolt design provides more aftermarket choices. On these vehicles, classic chrome Cragar SS or Magnum 500 wheels look great, combining modern tire choices with vintage design.

Dodge Dart IV (1967–1976) Wheel Fitment Specifications

Thanks to its muscular look and high-performance trimming, the fourth-generation Dodge Dart is maybe the most popular. Built between 1967 and 1976, it converted to a 5x4.0" (5x101.6mm) bolt pattern, which makes it far simpler now to obtain wheels that fit. Offering more tire options, factory rim sizes climbed to 14x5.5 inches. Depending on trim and package, the hub bore stayed at 59.2mm; offsets ranged from 0mm to +15mm. Usually, E78-14 or F70-14 bias-ply, stock tire widths convert to roughly 195/75R14 radial tires.

Wider wheels and tires are something this generation can manage better than previous models Those seeking a meaner stance sometimes migrate to 15x7 or 15x8-inch wheels with an offset of +0 to +6mm. Although suspension condition and ride height can still influence fitment, especially at the rear, this lets 235/60R15 tires fit without serious problems.

Recommended Wheels and Tires

15-inch or 16-inch wheels, including 15x7 with 225/60R15 tires or 16x8 with 235/55R16 tires, are preferred by Dart IV aficionados striving for the ideal balance of old-fashioned muscle and modern traction. While maintaining the vintage appearance, the bigger wheel size improves cornering stability. Custom offsets help tune in that ideal flush stance without scratching the fenders; classic five-spoke or rally-style wheels complement the aggressive lines of the car.

Dodge Dart PF (2012–2016) Wheel Fitment Specifications

Dodge's 2012 resurrection of the Dart moniker enters a whole new realm of design and technology. Quite unlike its predecessors, the PF generation rides on a contemporary 5x110mm bolt pattern. On lower trims, factory rim widths were from 16x7 inches; on sporty variants like the GT, they went from 18x7.5 inches. With a 65.1mm hub bore and typically +41mm to +46mm offsets, handling and aerodynamics are much improved. Based on trim level, factory tire sizes ranged from 205/55R16 to 225/45R17 and 225/40R18.

Although this generation reacts well to aftermarket improvements, it's important to follow correct offsets and widths since the Dart PF's wheel wells have limited space, particularly up front. For a better look and crisper handling without compromising ride quality, many owners choose 18x8-inch wheels with 225/40R18 tires.

Recommended Wheels and Tires

Choosing 17x7.5 or 18x8-inch wheels with an offset of about +42mm for the Dart PF offers a balanced stance and helps to avoid rubbing on suspension components or fenders. Complementing 225/45R17 or 235/40R18 tires, the automobile looks sportier while still staying comfortable. Drivers who want performance without additional weight can find excellent choices in lightweight flow-formed or forged wheels from companies like Enkei or OZ Racing.

How to Measure Wheel Fitment on Your Dodge Dart

Measuring wheel fitting is not as difficult as a first impression. Starting with the bolt pattern, either measure the distance between two opposing studs or use a bolt pattern gauge. Measure the hub bore, then, for accuracy, using a digital caliper. Look at the tire sidewall or examine the back of the wheel for hints on the rim size. Though a bit more difficult, offset can be determined by computing the distance from the mounting surface of the wheel to the centerline. Read the sidewall numbers to find your tire size; they reveal width, aspect ratio, and rim diameter.

Cross-reference these figures always using your Dart's model year and generation. See your car handbook or a reliable fitment guide if in doubt. This thoroughness guarantees that the wheels you select fit exactly the first time, therefore saving time and money.

Common Fitment Issues and Solutions

Common fitment issues include rubbing tires, wrong hub diameters, or misaligned offsets that  affect many Dart owners. Older models—especially the Dart III and IV—may run bigger wheels and endure tire rubbing on fends or suspension. Staying within advised widths and offsets can help; another option is to think about rolling the fenders. Using improper hub bore wheels without hub-centric rings usually causes vibration for Dart PF models; always make sure the hub bore matches or uses quality adapters.

Another problem is incorrect offsets, which force the wheels either too far in or out, therefore compromising stability and appearance. Either make little adjustments or stick near to stock offsets. Make sure spacer kits are safe and of high quality before using them.

Buy Dodge Dart Wheels and Tires at Hulk Offsets

Hulk Offsets has your back if you are looking for the ideal tires and wheels for your Dodge Dart. We have a large range of wheels from reliable manufacturers, from the elegant lines of a 2014 Dart GT to the nostalgic appeal of a '67 Dart Swinger. Guaranteed is our fitment guide, making sure you receive the correct bolt pattern, rim size, hub bore, offset, and tire size.

At Hulk Offsets, we are not only wheels. We are automobile buffs who know your Dart needs the ideal posture and performance. Take advantage of free shipping, fitment guarantees, and a committed staff to always have fitting answers. Check our stock and bring your Dart to life.

Conclusion

Selecting the correct tires and wheels improves the appearance, handling, and safety of your Dodge Dart, not only filling wheel wells. Every generation has different fitment requirements; knowing those specifics helps you to navigate your upgrading process. Your wheel arrangement can make the entire car look different from the traditional Dart IV muscle to the sleek modern lines of the Dart PF.

Here at Hulk Offsets, you may choose wheels for your Dart's appearance and driving manner. Check your specs, investigate your choices, and drive boldly knowing your Dart is riding on the correct set of shoes.
